High precision smt 12 layers pcba

High precision smt 12 layers pcba

1) Place of Origin: Shenzhen, China

2) Base Material: FR-4

3) Copper Thickness: 6 oz

4) Board Thickness: 3mm

5) Min. Hole Size: 0.2mm

6) Min. Line Width: 0.075mm

7) Surface Finishing: HASL

8) Product Item: Fast Delivery PCB Manufacturer 015

9) Solder mask color: Blue

10) Layer: 4 Layers


All multilayer boards are printed with 36t screen, the resistance welding oil is 50 tons thicker than the traditional 43t, which provides reliability guarantee for the bga and more precise fine lines.


Details

Custom pcb board with high quality double side

Custom pcb board with high quality double side

Custom pcb board with high quality double side


Custom pcb board with high quality double side

High precision smt 12 layers pcba

PCB processing capability

PCB serviceProcess capability
Layer1-20 layers
Maximum size≤600*500mm
Thickness0.1-5.0mm
Wire copper foil thickness17-343um(10oz)
Minimum linewidth / line distance0.075/0.065mm(3mil/2.8mil)
Minimum aperture0.15mm(6mil)
Minimum welding pad0.2mm(8mil)
Impedance control+/-10%
Shape processing accuracy+/-0.10mm(4mil)
Board typeFR-4, aluminum - base, copper -base, ROGERS, ARLON, Teflon, composite
Surface treatmentTin spray, ENIG, Immerse Au, immersion silver, im mersion tin, osp, gold osp, electrospray tin


PCB ASSEMBLY CAPABILITY

SMT serviceProcess capability
Processing typeSMT, DIP, After welding, test
Maximum boardL50×W50mm~L510×W460mm
Maximum thickness3mm
Minimum thickness0.5mm
Minimum component1005
Maximum component size150mm*150mm
Minimum pin component spacing0.3mm
Minimum bga spacing0.3mm
Maximum component mounting
accuracy(100FP)
Whole assembly accuracy up to ±50 micron,whole
process repetition accuracy ±30 micron.
SMT capacity4 million pins / day
DIP capacity100 thousand/ day
