Brand Name: HK CT TECH OEM PCB
Model Number: Double sided, Multilayer pcb
Base Material: FR4, Rogers, Aluminum
Copper Thickness: 0.1oz-8oz
Board Thickness: 0.2mm-4mm
Min. Hole Size: 0.1mm-1mm
Surface Finishing: HASL,LEAD FREE HASL,OSP
Product name: Shenzhen prototype design service pcb circuit boards
PCB type :Customized Electronics Manufacturing
Optional laminate
Material: Alu/Aluminum,FR4/FR-4,Copper,Ceramic,Rogers
Solder mask color: Blue,Red,Purple,Yellow,White,Green,Black
Number of Layer: 2 layer,8 layer,multi-layer PCBB
Certification of quantum board led: ISO/UL/TS16949/RoHS/TS16949
PCB Standards: IPC-A-610 D/IPC-III Standard
Service: PCBA,PCB&PCBA Design&Clone&Production
Application: Consumer Electronics,Industrial,Electronical Products,Battery Pack
PCB Assembly service: SMT THT DIP
PCB ASSEMBLY CAPABILITY
| SMT service | Process capability |
| Processing type | SMT, DIP, After welding, test |
| Maximum board | L50×W50mm～L510×W460mm |
| Maximum thickness | 3mm |
| Minimum thickness | 0.5mm |
| Minimum component | 1005 |
| Maximum component size | 150mm*150mm |
| Minimum pin component spacing | 0.3mm |
| Minimum bga spacing | 0.3mm |
| Maximum component mounting accuracy(100FP) | Whole assembly accuracy up to ±50 micron,whole process repetition accuracy ±30 micron. |
| SMT capacity | 4 million pins / day |
| DIP capacity | 100 thousand/ day |
