Place of Origin: Guangdong, China (Mainland)
Brand Name: HKCT TECH OEM PCB
Model Number: FR-4 TG130/150/170 multi pcb
Base Material: Fr-4 TG130/150/170
Copper Thickness: 1oz-2oz
Board Thickness: 7mm
Min. Hole Size: 0.15mm, 0.20mm
Surface Finishing: HASL,LEAD FREE HASL,OSP
Product name: Factory price high TG Fr4 Metal Alu Small Printed Circuit Board
PCB type: Electronics Manufacturing
Number of Layer: Double Layer PCB,Multilayer PCB
Certification of quantum board led: ISO,SGS,ISO,ROHS
Testing service: Omron AOI/X-Ray/ICT/Solder Paste Testing/Function Testing
Service: PCBA,PCB&PCBA Design&Clone&Production
Application: Consumer Electronics,Industrial,Electronical Products,Battery Pack
PCB Assembly service: SMT THT DIP
PCB processing capability
| PCB service | Process capability |
| Layer | 1-20 layers |
| Maximum size | ≤600*500mm |
| Thickness | 0.1-5.0mm |
| Wire copper foil thickness | 17-343um（10oz） |
| Minimum linewidth / line distance | 0.075/0.065mm（3mil/2.8mil） |
| Minimum aperture | 0.15mm（6mil） |
| Minimum welding pad | 0.2mm（8mil） |
| Impedance control | +/-10% |
| Shape processing accuracy | +/-0.10mm（4mil） |
| Board type | FR-4, aluminum - base, copper -base, ROGERS, ARLON, Teflon, composite |
| Surface treatment | Tin spray, ENIG, Immerse Au, immersion silver, im mersion tin, osp, gold osp, electrospray tin |
PCB ASSEMBLY CAPABILITY
| SMT service | Process capability |
| Processing type | SMT, DIP, After welding, test |
| Maximum board | L50×W50mm～L510×W460mm |
| Maximum thickness | 3mm |
| Minimum thickness | 0.5mm |
| Minimum component | 1005 |
| Maximum component size | 150mm*150mm |
| Minimum pin component spacing | 0.3mm |
| Minimum bga spacing | 0.3mm |
| Maximum component mounting accuracy(100FP) | Whole assembly accuracy up to ±50 micron,whole process repetition accuracy ±30 micron. |
| SMT capacity | 4 million pins / day |
| DIP capacity | 100 thousand/ day |
