High quality Inverter PCB layout design / high quality wireless mouse pcb layout design

High quality Inverter PCB layout design / high quality wireless mouse pcb layout design

Brand Name: HK CT TECH

Model Number: 0.3mm-3.6mm

Base Material: fr-4 flex-rigid pcb board, Fr-4,ALu,Roger,leadfree

Copper Thickness: 2oz

Board Thickness: 1.6mm

Min. Hole Size: 0.25

Min. Line Width: 4mil

Min. Line Spacing: 4mil

Surface Finishing: imersion gold

Product name: Oem pcb assembly

 Service: PCBA Board Service Prototype PCB Assembly

Surface finishing: imersion gold/tin/Au/silver/tin,Osp,Hasl

Solder mask color: GreenWhiteRedBlueBlack

PCBA type: Electronics Manufacturing board

Layer: 1-48 Layers (include Rigid-Flex PCB)

PCB Fireproof: 94v0

Certificate: ISO/ISO/RoHS/TS16949


High quality Inverter PCB layout design / high quality wireless mouse pcb layout design

PCB prototype (PCB proofing)

With the development of the electronic technology industry, the PCB circuit board industry has also been rising rapidly. According to the number of layers, the circuit board can be divided into three major categories: single-side, double sides, and multilayer board. Before mass production of PCBs, it is common to verify the design and functions of PCB by prototyping. PCB price for sample board is very sensitive. China has the largest number of pcb manufacturers in the world and countless PCB circuit board proofing manufacturers. You will find that PCB China quotations are very different. Many customers pay more attention to the cheap PCB manufacturer instead of quality when they look for prototype printed circuit board, which leading to even worse consequences.

CTT has 18 years of experience in PCB prototype. We have produced countless PCB prototype for many engineers, PCB design companies, electronics manufacturers and so on. There is a wealth of experience in the hole, line width and surface treatment of the board.

Prototype PCB same high quality standards as standard PCB

CTT provides high quality and low cost services for prototype printed circuit boards. Our printed circuit boards are fully compliant with ISO9001:2008 quality management systems. We have an quality control department to verify that all operating procedures are in compliance with regulations and in accordance with the PCB manufacturing process.


According to your custom requirements, we can provide prototype PCB within 3-7 days.

Please check below table about our circuit board prototype capabilities:

Quality   GradeStandard IPC 1
Number   of Layers1 -48 layers
Order   Quantity5pcs - 100pcs
Delivery   Time2 - 7 days
Board   SizeMax 500*600mm
Board   Thickness0.25mm - 5mm
Copper   Weight1.0oz - 6.0oz
Min   Tracing/Spacing3mil/2.8mil
Solder   Mask ColorGreen, White, Blue, Black, Red,   Yellow
Surface FinishLead Free HASL - RoHS
HASL -   Hot Air Solder Leveling
ENIG -   Electroless Nickle/Immersion Gold - RoHS
Min   Drilling Hole Diameter8mil
NPTH   Hole Size Tolerance±.002" (±0.05mm)
Min   Width of Slot Hole (PTH)0.6mm
PTH Hole   Size Tolerance±.003" (±0.08mm) -   ±.006" (±0.15mm)
Surface/Hole   Plating Thickness20μm - 30μm
SM   Tolerance (LPI)±.003" (0.075mm)

Get an Instant PCB Prototyping Quote NowYou can click right side button contact us for a detailed quote!
