SMT PCBA FR4 PCB boards power supply boards assembly

SMT PCBA FR4 PCB boards power supply boards assembly

Place of Origin: Shenzhen, China

Brand Name: customized

Model Number: C-PCBA-252

Base Material: FR-4

Copper Thickness: 0.5 OZ-11OZ (18 um-385 um)

Board Thickness: 1.6mm, 3.2mm, 0.2mm, 4.5mm, 1.6mm, 3.2mm

Min. Hole Size: 0.07--2.0 mm

Min. Line Width: 0.075mm( 3mil)

Min. Line Spacing: 0.065mm (2.8mil)

Surface Finishing: Sensor PCB PCBA Immersion Gold

Min Trace Width (a): 0.1mm (4 mil)

Board Material: FR-4 glass epoxy, FR-4 high Tg, Rohs compliant, Aluminum, Rogers, etc

Board Type: Rigid, Flexible, Rigid-flexible

Number of Layer: 1,2,4 or 6, up to 48 layers


All multilayer boards are printed with 36t screen, the resistance welding oil is 50 tons thicker than the traditional 43t, which provides reliability guarantee for the bga and more precise fine lines.
